RH12-1.37
Description:
Large action range and fast dynamic response
Compact structure and strong overload capacity
Adopts bus structure, easy to expand
Parameter
| Product model | RH 12-1.37 |
| Structure | Vertical multi-joint |
| Control axis | 6 axis |
| Maximum load | 12kg |
| Repeat positioning accuracy | ±0.03mm |
| Maximum speed | 1 axis 220°/sec 2 axis 220°/sec 3 axis 250°/sec 4 axis 350°/sec 5 axis 550°/sec 6-axis 650°/sec |
| Range of motion | 1 axis ±170° 2 axis +170°/-90° 3 axis +80°/-150° 4 axis ±210° 5 axis ±145° 6-axis ±360° |
| Temperature | 0-45℃ |
| Humidity | 20%-80% (no condensation) |
| Installation form | Ground installation, inclined installation, suspension installation |
| Machine weight | 177kg |
